| Type |
WSA-NCV |
WSC-NCV |
| Phase |
Single Phase |
Single Phase |
| Line Type |
2 Line |
2 Line |
| Frequency |
50/60Hz±1Hz |
50/60Hz±1Hz |
| Constant Input Voltage |
100/110V |
200/220V |
| Voltage change range |
90~121V |
180~242V |
| Constant Output Voltage |
100/110V |
200/220V |
| Constant Output Current |
6.10.20.30A |
3.5.10.15A |
| Voltage range |
0~95% |
0~95% |
| Accuracy voltage output |
±0.5% |
±0.5% |
| Load change |
0~100% |
0~100% |
| Load power range |
-20~+70% |
-20~+70% |
| Wave dist range |
1% |
1% |
| Efficiency |
95%以上 |
95%以上 |
| Power factor |
0.98以上 |
0.98以上 |
| Call time |
0.2S |
0.2S |
| Soft up time |
0.2S - 5S Possible to change |
0.2S - 5S Possible to change |
| Current limit |
Hugging down in 120%(possible to change to LIMIT・VR) |
Hugging down in 120%(possible to change to LIMIT・VR) |
| Protect over current |
Output shutdown in 200% (self maintenance・automatic exchange return) |
Output shutdown in 200% (self maintenance・automatic exchange return) |
| Signal control |
Current signal (4-200mA)・Voltage signal(1.5V)・Manual setting(1KΩVR)selling separately |
Current signal (4-200mA)・Voltage signal(1.5V)・Manual setting(1KΩVR)selling separately |
| Internal machine |
MIN(minimum setting)0 - 100%・DAMP(Gradient setting)100 - 0%･LIMIT(Current limit)100 - 0% |
MIN(minimum setting)0 - 100%・DAMP(Gradient setting)100 - 0%･LIMIT(Current limit)100 - 0% |
| Ambient Temperature |
0~40℃ |
0~40℃ |
Ambient Humidity
|
35~93% |
35~93% |
| Increase temperature |
within 80deg |
within 80deg |
| Insulation Voltage Endurance |
More than 50MΩ at DC500 megger |
More than 50MΩ at DC500 megger |
| Insulation Voltage Endurance |
AC1500V for 1 minute |
AC1500V for 1 minute |
